A skilled attacker who has spent any time studying forensics will know to modify file timestamps. Some will go further and delete their tools, clear event logs, and rename artefacts before exfiltrating or detonating. What most do not account for, because most training does not cover it carefully, is that NTFS keeps a layered audit trail spread across at least three separate structures, and cleaning one of them rarely touches the others.

cover

The Master File Table, the USN Journal, and the $LogFile each capture a different dimension of file system activity, at a different granularity and with different retention characteristics. When an analyst knows how to correlate all three, the story they tell is significantly harder to fully suppress than anything a single log or a timestamp suggests.

This article walks through that structure in practical terms: what each artefact contains, how to extract it, and where the intersections between them are most useful for investigations.

In brief

  • NTFS stores file metadata in at least two independent locations per file: $STANDARD_INFORMATION and $FILE_NAME inside the MFT. Attackers can modify one but not both through standard APIs.
  • The USN Journal logs every file system change event sequentially, survives file deletion, and typically retains approximately 20 days of activity on an active volume.
  • The $LogFile is a low-level transaction log that records redo/undo operations on NTFS metadata, providing independent evidence of when attributes were last written.
  • dfir_ntfs and MFTECmd are complementary tools: one gives you programmatic access to raw NTFS structures; the other gives you analyst-ready CSV output for timeline correlation.
  • File carving remains useful when MFT metadata is corrupted or missing, but it is best treated as a last resort.
  • Correlating all three artefact layers produces a more robust timeline than any single source can provide.

The structure underneath the filesystem

Before getting into tooling, it helps to have a clear model of what NTFS actually stores about a file, because the forensic value of these artefacts only becomes obvious once you understand the redundancy involved.

Every file on an NTFS volume has at least one entry in the Master File Table, or $MFT (earlier overview). Each MFT entry is 1024 bytes and contains, among other things, two distinct sets of timestamps. The first set lives in the $STANDARD_INFORMATION attribute: the four MACB timestamps (Modified, Accessed, Created, $MFT entry modified) that most tools and the Windows Explorer interface expose. The second set lives in the $FILE_NAME attribute, which the NTFS kernel driver writes when the file is created and updates under a narrower set of circumstances. The critical forensic implication is that $FILE_NAME timestamps are written by the kernel and cannot be modified through standard Win32 APIs like SetFileTime. Most timestomping tools only reach $STANDARD_INFORMATION.

That asymmetry is the most reliable single indicator of timestamp manipulation available in NTFS forensics. A file where $STANDARD_INFORMATION Born is earlier than $FILE_NAME Born is, under normal filesystem operation, an impossibility. The kernel copies $SI values from $FN at creation time; any later backdating of $SI will diverge from the kernel-written $FN values. When you see that divergence, you are reading a contradiction in the metadata record, not making an inference.

The MFT also stores the file’s logical size, physical allocation, attribute list, and, for small files (typically under around 700 bytes), the file content itself as a resident attribute inside the MFT entry. This matters for carving: deleting a resident file does not free any cluster, it just marks the MFT entry as available for reuse. The content survives until the entry is overwritten.

USN Journal: the filesystem’s event stream

The USN Journal (\$Extend\$UsnJrnl) is an NTFS feature that has been available since Windows 2000 (dedicated post) and is enabled by default on modern Windows systems. Its primary stream, $J, records a sequential log of every file system change on the volume: file creates, renames, deletes, attribute changes, security descriptor updates, and more. Each record contains a 64-bit USN identifier, the filename, a parent MFT reference, a reason code bitmask (for example, USN_REASON_FILE_CREATE, USN_REASON_RENAME_OLD_NAME, USN_REASON_BASIC_INFO_CHANGE), and a timestamp.

The $MAX alternate data stream stores metadata about the journal itself, including the configured maximum size, which controls how far back the journal extends. On an active volume, this typically covers approximately 20 days of activity, though heavily active systems may retain significantly less. You can inspect this on a live system: fsutil usn queryjournal C:

For DFIR purposes, the USN Journal is valuable because it tracks changes rather than static file states. A file that has been deleted, timestomped, or renamed still leaves records behind. Consider the case of a tool deployed by an attacker that was later cleaned up with SDelete or a similar secure deletion utility. SDelete’s characteristic behaviour is to rename the target file multiple times before deleting it (AAA.AAA, BBB.BBB, and so on), then issue the delete. Each rename operation generates a RENAME_OLD_NAME and RENAME_NEW_NAME record in the USN Journal, producing a distinctive signature that survives the deletion itself.

The timestomping detection case is equally clean. A USN_REASON_BASIC_INFO_CHANGE record at a specific timestamp, correlated with the $SI/$FN discrepancy in the MFT, gives you two independent sources converging on the same event. Adding a Prefetch file for the timestomping binary, if it executed, gives you a third.

To extract the $J stream from a forensic image, you need to bypass the filesystem layer, since Windows will not give you direct access to NTFS metadata files through normal file operations. Two approaches work well in practice.

Using MFTECmd (Eric Zimmerman’s tool): MFTECmd.exe -f “E:\Evidence$J” –csv C:\output\ –csvf usn.csv

The resulting CSV includes UpdateTimestamp, Name, FileAttributes, UpdateReasons, ParentEntryNumber, and ParentSequenceNumber. To reconstruct full paths, you need to parse the $MFT alongside it and join on the parent MFT entry number: MFTECmd.exe -f “E:\Evidence$MFT” –csv C:\output\ –csvf mft.csv

Load both in Timeline Explorer and join on ParentEntryNumber. From there, filtering on USN_REASON_FILE_DELETE within your incident window, or looking for FILE_CREATE followed by FILE_DELETE within 60 seconds, covers a large fraction of malicious tool deployment and cleanup patterns.

dfir_ntfs: going below the surface

dfir_ntfs, the Python library developed by Maxim Suhanov (original post), targets a different use case than MFTECmd. Where MFTECmd is optimised for analyst-facing CSV output, dfir_ntfs is a programmatic interface to raw NTFS internals. It parses $MFT, $UsnJrnl:$J, and $LogFile directly, can work against volume images and volume shadow copies, and exposes the underlying structures in Python objects rather than spreadsheet rows.

Installation is straightforward:

pip3 install https://github.com/msuhanov/dfir_ntfs/archive/1.1.19.tar.gz

A minimal MFT parsing session:

import dfir_ntfs.MFT as MFT

with open('$MFT', 'rb') as mft_file:
    mft = MFT.MasterFileTableParser(mft_file)
    for file_record in mft.file_records(True):
        if not file_record.is_in_use():
            continue
        si = file_record.get_standard_information()
        fn = file_record.get_file_name()
        if si and fn:
            si_created = si.get_created_time()
            fn_created = fn.get_created_time()
            if si_created and fn_created:
                if si_created < fn_created:
                    print(f"[TIMESTOMP] {fn.get_file_name()} SI:{si_created} FN:{fn_created}")

That pattern, scanning for MFT entries where $SI Born is earlier than $FN Born, is one of the fastest automated timestomping detection passes you can run on a raw image. The NTFS driver cannot produce that condition under normal operation, so false positives are rare and usually traceable to known edge cases (volume cloning, VSS interactions) rather than attacker activity.

The library also provides access to volume shadow copies, which is where many investigations recover artefacts that an attacker deleted after gaining access but before VSS snapshots were removed. From a shadow copy, you can extract a $MFT state from an earlier point in time and compare it against the live MFT to identify entries that have been deleted or modified in between.

The third layer: $LogFile and what it tells you

The $LogFile is the NTFS transaction journal, a structure designed primarily to ensure filesystem consistency across crashes. It is also an independent source of metadata write events that most analysts overlook entirely.

$LogFile records redo and undo operations for NTFS metadata updates, including attribute changes, in terms of Log Sequence Numbers (LSNs). Each MFT entry carries the LSN of the most recent transaction that modified it. When you find a suspicious timestamp in $STANDARD_INFORMATION and want to independently confirm when it was last written, the corresponding $LogFile entry for that LSN gives you an out-of-band timestamp for the transaction itself.

Practical extraction is straightforward with NTFS Log Tracker (available at ForensicNote) or through dfir_ntfs’ LogFile.py module. In Timeline Explorer, loading both the MFT CSV and the $LogFile CSV and cross-referencing by LSN gives you a three-source timeline per file:

  1. $FILE_NAME Born: kernel-written, reliable, rarely tampered with.
  2. $STANDARD_INFORMATION timestamps: the attacker-facing values, modified by timestomping tools.
  3. $LogFile LSN timestamp: when the NTFS driver last wrote the $SI attribute, independent of the value it wrote.

When all three converge, you have a solid story. When $LogFile shows a write to $STANDARD_INFORMATION at a time inconsistent with the $SI value itself, you have direct evidence of manipulation, not just an anomaly.

File carving: a fallback with limitations

Once you have exhausted MFT, USN Journal, and $LogFile analysis, file carving is what you turn to when filesystem metadata is genuinely gone, either because the attacker went after NTFS structures directly (as modern wipers like HermeticWiper and CaddyWiper do), or because the MFT entry was reallocated before the investigation started.

I covered carving techniques in more detail in Some thoughts about file carving. Basic carving works on header and footer signatures (magic numbers): %PDF / %EOF for PDF files, 0xFFD8 / 0xFFD9 for JPEG, CA FE BA BE for Java class files, and so on. The Gary Kessler signature list remains the reference here. Basic carving assumes the file is not fragmented and the beginning of the file is not overwritten.

Advanced carving handles fragmented files, where fragments may be non-sequential or have gaps. It relies on content analysis rather than just header/footer matching, which is computationally expensive but necessary for email archives, database files, or anything that grows over time.

The practical limitation is that carving produces no provenance. A recovered file has no MFT entry, no USN Journal record, no chain of custody in the filesystem sense. It exists as bytes. What it tells you about when something happened, or who performed an action, depends entirely on internal file metadata (EXIF data, document properties, embedded timestamps) rather than filesystem artefacts. For court purposes, and for timeline reconstruction, that is a meaningful limitation.

When the MFT entry survives but the file is marked as deleted, you can frequently recover both the file and its metadata. The MFT entry still contains the file’s timestamps, size, and allocation. In that case, you are accessing a deleted but intact record rather than carving from raw fragments, and the forensic value is substantially higher.

Putting it together: a practical investigation workflow

The standard starting point is always the $MFT, because it is the index to everything else. Extract it first, parse it with MFTECmd, and load the output in Timeline Explorer. At that stage you have a complete list of files the filesystem knows about, including deleted entries whose MFT records have not yet been reused.

From there, the sequence depends on what you find. If the incident window is clear, filter the $MFT timeline to that window and identify the files of interest. For each suspicious file, pull the USN Journal records for the corresponding MFT entry number and check whether the timestamps are consistent. Any USN_REASON_BASIC_INFO_CHANGE event at a time that does not match the $SI timestamps is an immediate red flag.

For files where you suspect timestomping specifically, compare $SI and $FN timestamps directly. A divergence greater than a few seconds, or a $SI Born earlier than $FN Born, warrants $LogFile analysis to confirm when the $SI attribute was last written.

If you are working with dfir_ntfs in a scripted pipeline, the library gives you the tools to automate all of this across an entire image: iterate MFT records, flag $SI/$FN discrepancies, cross-reference against USN Journal records for the same entry number, and export findings to a structured format for timeline import. For large-scale triage across multiple machines, that scripted approach scales better than loading individual CSVs in a GUI tool.

Volume shadow copies are worth checking before you conclude that deleted artefacts are unrecoverable. dfir_ntfs handles VSS parsing natively, and comparing the MFT state across shadow copy snapshots can surface files that were present at a known point in time and subsequently removed.

The NTFS artefact layer is not indestructible. As the evolution of disk wipers shows, modern destructive malware increasingly attacks NTFS metadata structures directly, and a sufficiently thorough wiper can corrupt or destroy the $MFT, $UsnJrnl, and $LogFile before a response team arrives. In those cases, carving is genuinely what remains. But that scenario is the exception rather than the rule. In most investigations, the NTFS layer is intact, the attacker assumed that deleting files and clearing event logs was sufficient, and the three-source correlation described here recovers considerably more than the attacker intended to leave behind.

FAQ

What is the USN Journal and why does it matter in DFIR?

The USN Journal is an NTFS change-log that records every file system event, including creations, renames, deletions, and metadata changes. It persists even after files are deleted, making it essential for timeline reconstruction and detection of anti-forensic techniques like timestomping.

How do you detect timestomping using NTFS artefacts?

By comparing the $STANDARD_INFORMATION and $FILE_NAME timestamp attributes in the MFT. If $STANDARD_INFORMATION timestamps predate $FILE_NAME timestamps for the same file, the kernel-written timestamps have been tampered with. The USN Journal and $LogFile provide independent corroboration of when the manipulation actually occurred.

What is dfir_ntfs and how does it differ from MFTECmd?

dfir_ntfs is a Python library by Maxim Suhanov that parses $MFT, $UsnJrnl, $LogFile, volume images, and shadow copies, exposing raw NTFS internals programmatically. MFTECmd is a Windows GUI/CLI tool that produces analyst-ready CSV output for Timeline Explorer. They are complementary rather than competing tools.
